ZYC960 Ton Hydraulic Static Pile Driving Machine compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.T-works summarizes the defects of past products, and continuously improves them. The specifications of ZYC960 Ton Hydraulic Static Pile Driving Machine can be customized according to your needs.
Product Introduction
Hydraulic Static Pile Drivers are featured with no noise, no vibration, no pollution and no rubbish left in construction site.It can work with H-piles, precast concrete and steel piles with different shapes,like round,square and tapered shape. There are series models range from 60T to 1200T
It is adopted the hydraulic system design of large power and high flow,the precast pile entirely depends on the hydraulic static pressure so that the pile can be pressed into the ground steadily and quietly.
The pressing-pile speed amounting to 300-800 meters within 8hours, which its quite more efficient than other conventional pile drivers.
This unique construction method with non-pollution has gradually taken place of the pile hammer.
To ensure the high working efficiency of the whole machine, we use hydraulic systems with big power and great flow, the pile driving mechanism with multi-speed control and being quick in getting ready for operation.
To ensure the high reliability of our products which engineering machines should possess, we improve the design and use very reliable materials or components which we select carefully in the process of purchasing.
For example we use inverted cylinder as a supporting leg which has become a patent in our country so as to avoid the easy breakage of cylinder which was the case with traditional design.
Since we have constantly improved our design of pile drivers for more than 10 years, every part of the machine is easy to be taken apart, which provides convenience in transportation and maintenance.
Compared with the pile drivers made by other companies, ours are more convenient to be taken apart and shipped as the connection and lay out of the long boat and the short boat are different.Take the drivers cab for example; it can be opened at the middle so that the lifting arm of the crane can pass through it during transportation. Besides, the side piling mechanism can be taken off so as to reduce the length of machine to be shipped and greatly reduce the weight of separated units in transportation.
Our products are multi-function static hydraulic pile drivers with embracing pile driving, top-pressing pile driving or both at the same time because they are well combined with each other.
Our products have bigger capacity of side piling and corner piling than those of other companies, and the power of side or corner piling reaches 60% of the middle piling.
Our pile drivers can work with a variety of piles, square piles or round piles or other shape of steel piles, no matter thin-walled round concrete piles or thick-walled ones.
To keep up with the development in the engineering machinery of the world, we will integrate all useful high technologies from machine-building, electricity, hydromechanics and electronics into our products and meet different individual needs of our customers.
For example, we can, if any customer requires, install a position-controller for the crane, and a digital screen showing the tonnage of piling force, etc.
Product Information
| Parameters of ZYC960 | Parameter value of ZYC960 |
| Rated Piling Force (10KN) | 960 |
| High Piling Speed / Low Piling Speed(m/min) | 9.8 / 1.6 |
| Single Piling Stroke (m) | 1.90 |
| Longitudinal Single Travel Distance / Horizontal Single Travel Distance | 3.6 / 0.7 |
| Walking Rotation Angle (°) | 11 |
| Lifting Stroke (m) | 1.20 |
| Maximum Applicable Pile Diameter(mm) Square / Round | 600 / 800 |
